Personal Hi-Fi Amplifier Project
Hardware DIY Audio Electronics
Complete KiCad project for a personal high-fidelity audio amplifier.
Project Overview
This project contains the complete design files for building a personal hi-fi amplifier, from schematic to PCB layout.
What’s Included
- Schematic — Complete amplifier circuit design
- PCB Layout — Production-ready board files
- Gerber Files — Ready for fabrication
- Documentation — Build notes and assembly guide
Files Available
| File | Description |
|---|---|
personal-amp.kicad_sch | Schematic design |
personal-amp.kicad_pcb | PCB layout (191KB) |
personal-amp.kicad_pro | Project file |
personal-amp-backups/ | Project backups |
| Gerber files | For PCB fabrication |
Design Features
- High-quality audio performance
- Standard through-hole components
- Clear labeling and silkscreen
- Proper grounding and shielding
- Professional layout practices
Applications
- Personal audio projects
- Learning PCB design
- Hi-fi system building
- Audio electronics education
Build Status
The project includes complete KiCad files with backups, making it ready for fabrication or modification.
Full KiCad project files, gerbers, and build notes available in the project repository.
